W2-A Access Control Waterproof

W2-A Waterproof Standalone Proximity Reader

• Related Articles

• Neo Access Control - Installation & Specifications

  Introduction The HAR300 Access Control is most commonly installed in common areas/gates/front doors for accommodation sites. This unit can also be used in conjunction with the Lock-S lift control system as the ID reader. Supporting technologies ...

• Neo ACR & Neo Cloud Lock - User Guide for Local Management

  Preface Local Management and programming (as per below) are not required if you are managing locks access via the mobile App or via a Web Console. Please Note: Battery operated Neo Locks are not recommended for use as "Common Doors". Get the Free App ...

• LMS Access Control System - Installation Guide

  To setup and program the access control reader ​ There are 2 main components of the Access Control System (ACS) which you some become familiar with.  There are also additional optional devices that comprise the ACS, a door release and the REX button. ...

• LMS - Access Control in Free Passage Mode

  Step # 1: Issue ACR Control Card by clicking on system settings >> Issue ACR Control Card Step # 2: Now set the parameters according to your requirement and click issue ACR card. Step # 3: Now Tap the issued ACR card on the access control and your ...

• Lock-S Lift Control

  Designate card access to assigned floors Specifications  Wiring Diagram ​ Function Guest cards can only access the permitted floors by swiping the card. Example: If the room is on the third floor, the guest can only reach the third floor. When ...
